Description
| Grade | 1000 Series: 1050 1060 1100 |
| 3000 Series: 3003 3004 3105 | |
| 5000 Series: 5052 5605,5083 | |
| 6000 Series: 6061 6063 | |
| 7000 Series:7005 7050 7075 | |
| 8000 Series: 8011 8021 8079 | |
| Thickness | 0.20-8.00mm |
| Width | 2400mm max. |
| Grade | 1000,3000,5000,6000,8000series |
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil weight | 1000-5000kgs |
| Coil OD | 1700mm max. |
| Temper | O, H12, H14, H16, H111, H22 ,H24, H26, H28,T4, T6,etc. |
| Features | 1) Smooth and flat |
| 2) Weather resistance | |
| 3) Good quality surface finish | |
| 4) Anti-corrosion | |
| 5) Anti-ultraviolet |
Chemical composition
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | 0.05 | 99.5 | ||
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | 0.05 | 99.6 | ||
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | 0.04 | 99.7 | ||
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.05 | 0.1 | 99 | ||||
| 1200 | Si+Fe:1.00 | 0.05 | 0.05 | 0.1 | 0.05 | 99 | |||
| 1235 | Si+Fe:0.65 | 0.05 | 0.05 | 0.05 | 0.1 | 0.06 | 99.35 | ||
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | 0.1 | remains | |||
| 3004 | 0.3 | 0.7 | 0.25 | 1.0-1.5 | 0.8-1.3 | 0.25 | remains | ||
| 3005 | 0.6 | 0.7 | 0.25 | 1.0-1.5 | 0.20-0.6 | 0.1 | 0.25 | remains | |
| 3105 | 0.6 | 0.7 | 0.3 | 0.30-0.8 | 0.20-0.8 | 0.2 | 0.4 | remains | |
| 3A21 | 0.6 | 0.7 | 0.2 | 1.0-1.6 | 0.05 | 0.1 | remains | ||
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50-1.1 | 0.1 | 0.25 | remains | |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | remains | |
| 5083 | 0.4 | 0.4 | 0.1 | 0.40-1.0 | 4.0-4.9 | 0.05-0.25 | 0.25 | remains | |
| 5154 | 0.25 | 0.4 | 0.1 | 0.1 | 3.1-3.9 | 0.15-0.35 | 0.2 | remains | |
| 5182 | 0.2 | 0.35 | 0.15 | 0.20-0.50 | 4.0-5.0 | 0.1 | 0.25 | remains | |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | 0.2 | remains | |
| 6061 | 0.40-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | remains | |
| 6063 | 0.20-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | remains | |
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.40-1.0 | 0.6-1.2 | 0.25 | 0.2 | remains | |
| 8011 | 0.50-0.9 | 0.6-1.0 | 0.1 | 0.2 | 0.05 | 0.05 | 0.1 | remains |
